Square beam with a top cylindrical cavity

Volumes

A - A 1x1x2 m beam with a cylindrical cavity in its end face. The cylindrical cavity has a 0.42426 m radius and 0.4 m height. Rotated so that its axis follows (1,1,-1). Similar to geometry 0017.

Surfaces

  1. “cyl” cylindrical cavity side surface

  2. “flat_+Y” small surface near the beam tip with normal (0,+1,0) before rotation

  3. “flat_-Y” small surface near the beam tip with normal (0,-1,0) before rotation

  4. “flat_+Z” small surface near the beam tip with normal (0,0,+1) before rotation

  5. “flat_-Z” small surface near the beam tip with normal (0,0,-1) before rotation

  6. “fix” base

  7. “load” beam top (excluding the cylindrical cavity)

Mesh

  • Target element size: 100.0 mm

  • 9 088 elements
